DH-HAC-HFW1400R Dahua CCTV Camera

Camera

Image Sensor

1/2.7 inch CMOS

Effective Pixels

2560(H)×1440(V), 4MP

Scanning System

Progressive

Electronic Shutter Speed

PAL: 1/25s–1/100000s
NTSC: 1/30s–1/100000s

S/N Ratio

>65dB

Minimum Illumination

0.02Lux/F2.0, 30IRE, 0Lux IR on

Fill Light Working Distance

20 m (65.6 ft)

IR On/Off Control

Auto; manual

IR LED Number

12

Pan/Tilt/Rotation Range

Pan: 0°–360°
Tilt: 0°–90°
Rotation: 0°–360°

Lens

Lens Type

Fixed-focal

Mount Type

M12

Focal Length

2.8 mm; 3.6 mm

Max. Aperture

F2.0 ;F2.0

Field of View

2.8 mm: 125° x 105° x 56°

(diagonal x horizontal x vertical)
3.6 mm: 104° x 87° x 47°

(diagonal x horizontal x vertical)

Iris Type

Fixed iris

Close Focus Distance

2.8 mm: 0.7m (2.3 ft)

3.6 mm: 1.1m (3.6 ft)

DORI Distance

Lens

Detect

Observe

Recognize

Identify

2.8 mm

49.8m (163.4 ft)

19.9m

(65.3 ft)

10m

(32.8 ft)

5m

(16.4 ft)

3.6 mm

64m

(210.0 ft)

25.6m

(84 ft)

12.8m

(42 ft)

6.4m

(21 ft)

Video

Frame Rate

CVI:

PAL: 4M@25fps; 1080P@25fps;

NTSC: 4M@30fps; 1080P@30fps

AHD:

PAL: 4M@25fps;

NTSC: 4M@30fps

TVI:

PAL: 4M@25fps;

NTSC: 4M@30fps

CVBS:

PAL: 960H;

NTSC: 960H

Resolution

4M (2560 × 1440); 1080P (1920 × 1080); 960 H (960 × 576/960 × 480)

Day/Night

Auto switch by ICR

BLC

BLC/HLC/DWDR

WDR

DWDR

White Balance

Auto; manual

Gain Control

Auto; manual

Noise Reduction

2D NR

Smart IR

Yes

Electronic Defog

Yes

Mirror

Off/On

Privacy Masking

Off/On (8 area, rectangle)
