HD-920-UNK skype conference room camera -skype for business meeting room solution
HD-920-UNK skype for business video conferencing hardware
Features:
* Full HD Color Video PTZ Camera 1080P@30, 1080P@25, 1080i@60, 1080i@50, 720P@60, 720P@50, 720P@30, 720P@25
* Image Sensor : 1/2.8″ Type Exmor CMOS
* Zoom : 20 Optical x 12 Optical zoom
* Pan Rotation Angle : 355° Pan,
* Tilt Rotation Angle : 45° Tilt
* Video Output : USB 3.0
* Power ON-OFF switch
* Auto/Manual focus/brightness/WB
* RS-232C/VISCA Protocol
| Image Sensor | Image Sensor | 1/2.8 Type ExmorCMOS |
| Effective Pix | 3.27 Megapixel | |
| Min. Illumination | 0.1Lux | |
| White balance | Auto/Manual | |
| Gain control | Auto/Manual | |
| Backlight compensation | On/Off | |
| Shutter speed | 1/1 – 1/10,000S | |
| S/N ratio | >50db | |
| Lens | Focus | f=4.7-90mmF1.6-3.5 |
| Iris | Auto/Manual | |
| Lens | 20x Optical x 12 Digital Zoom | |
| Horizontal view angle | 55.4° | |
| Video output | USB3.0 | |
| Signal system | 1080P@30,1080P@25, 1080i@60,1080i@50, 720P@60,720P@50 ,720P@30, 720P@25 ,PAL ,NTSC | |
| Control terminal | EIA/RS232C,EIA/RS485(Bidirectional) | |
| Control Protocol | VISCA,PELCO-D | |
| baud rate | 9600/38400bps | |
| patrol line | 4 cruise sequence | |
| preset position | 64 preset positions | |
| Speed Match | Pan/Tilt movement speed depends on camera module zoom in/out | |
| OSD Menu | Access to OSD Menu and adjust camera module parameters | |
| Image auto flp | Support Horizontal/Vertical image flip | |
| Pan movement speed | 1-60°/Second | |
| Tilt movement speed | 1-200 degree per second | |
| Pan movement range | 1-150 degree per second | |
| Tilt movement range | Up: 45 degree, Down: 45 degree | |
| Pan scanning automatically | Support Pan scanning automatically | |
| Boundary scanning | 0-355 degree (programmable) | |
| Remote controller | IR Wireless Remote controller P/T/Z | |
| Power supply | DC12V,2A | |
| L x W x H | 250mm x 140mm x 154mm | |
| Weight | 1380g | |
